Aesculap Clipper FAV5

Powerful and quiet, reliable and sturdy, developed for daily use – the machine for professionals, also with SnapOn blade system.

the sturdy technology of the Favorita, but with SnapOn blade set system, also compatible with Oster, Andis, Wahl and Moser brands
proprietary, bearing-mounted Aesculap motor - Made in Germany - powerful and very long-lasting
consistently good cutting results – wear-resistant metal rocker arm
suitable for continuous operation – well-tuned ventilation system and easy-clean air filter protect against overheating and ensure a long life
low-fatigue working thanks to the slim, ergonomically designed housing made from unbreakable specialist plastic
comfortable to use – switch at the front of the machine for comfortable one-handed operation
incl. blade set GT330 #10 (1,5 mm)

Ref. no.	Colour	PU	Pallet
GT105G	red	1/8	72 PAL

Technical data	Voltage	Mains frequency	Power	Blade set system	Drive	Drive	Stroke rate	Sound pressure level	Cable length	Weight	Protection class
GT105G	230 V	50 Hz - 60 Hz	35 W	SnapOn, Compatible	Universal	Worm wheel	approx. 2300 strokes/min	70 dB	5 m	650 gwithout cable	II

Item. No.	Description	GT105G
GT604	Clipper oil 90ml	x
GT605	Aesculap special grease 20ml	x
GT104212	Fan impeller	x
GT104213	Strain relief device	x
GT104225	Felt disk for top housing	x
GT104227	Shackle	x
GT104244	Slide ring for excenter wheel	x
GT104249	Rubber protection for switch	x
GT104319	Baeringbrush	x
GT104320	Baeringbrush	x
GT104614	Carbon brush	x
GT104803	Air filter	x
GT104815	Pole Pack St. Core 230V,	x
GT104840	Worm wheel mounted	x
GT104850	Circuit board complete	x
GT104865	Rotor packed	x
GT105326	Protective sleeve	x
GT105801	Motor housing bottom	x
GT105802	Motor housing top	x
GT105808	Oscillating arm of steel	x
GT105819	Suitecase for	x
GT300224	Oil felt 12x9	x
TA003544	front bearing for 35104 and	x
TA003820	Locking washer for	x
TA004631	Ball bearing rear on anchor	x
TA004637	Disks underneath worm wheel	x
TA004663	Cylinder screw for plates,	x
TA004691	Switch	x
TA009971	Mains cable 2x0,75qmm	x
TA021595	Connector block	x
GT105415	Blade Hinge Complete	x
TA015486	Case Insert for GT105819	x

Specific data
