Control for LED lighting

This lighting control allows you to switch the artificial lighting on or off, on a timer and regardless of existing daylight, or even achieve a constant light level (e.g. min. 200 lux) through automatic dimming.

This means it ensures ideal lighting conditions throughout the day and year while minimising electricity consumption.

Comfort for animals and humans!

controls lighting dependent on time and/or daylight
four different lighting circuits (groups) can be independently controlled, two of which with a dimming function
suitable for LED lights with 1...10V interface
standard surface-mount housing for mounting in the equipment room
Dust and moisture protection (IP65)
suitable e.g. for up to 50 150 watt lights (up to 15 lights on the dimmable circuits 1 and 2, and up to 10 lights on circuits 3 and 4)
supplied with a light sensor (can request up to four light sensors)
input for up to four button signals
easy to use with display and three buttons
with extensive documentation and terminal description

easy to install by your electric company

Items

Ref. no.	Material	Width	Height	PU
345000	Plastic	300 mm	450 mm	1	1

Accessories

Ref. no.	Description	Length	Width	Height	PU
345001	Sensor for control	11 cm	6.5 cm	3.5 cm	1

LED oval light, can be controlled as an optional night light (345606) via a separate lighting circuit

Technical data
345000
Supply voltage	230 V / 400 V
Fuse	B16 A
Pole Connectors	3-pin
Max. current value per output	16 A
Max. total power circuit 3 and 4	16 A
Number of circuits	4
Number of dimmable circuits	2
Max. switching capacity	11 kVA
Dimming function circuit 1 and 2	1...10 V
Number of max. light sensors	4
Number of max. button signals	4
Protection class	IP65

Technical data	Supply voltage	Fuse	Pole Connectors	Max. current value per output	Max. total power circuit 3 and 4	Number of circuits	Number of dimmable circuits	Max. switching capacity	Dimming function circuit 1 and 2	Number of max. light sensors	Number of max. button signals	Protection class
345000	230 V / 400 V	B16 A	3-pin	16 A	16 A	4	2	11 kVA	1...10 V	4	4	IP65

Technical data	345000
Supply voltage	230 V / 400 V
Fuse	B16 A
Pole Connectors	3-pin
Max. current value per output	16 A
Max. total power circuit 3 and 4	16 A
Number of circuits	4
Number of dimmable circuits	2
Max. switching capacity	11 kVA
Dimming function circuit 1 and 2	1...10 V
Number of max. light sensors	4
Number of max. button signals	4
Protection class	IP65

Preview image	Item. No.	Description	345000
	345001	Sensor for LED Light Control	x
	345002	Controller for Control	x
