Cow cleaning machine HAPPYCOW MaxiSwing

The special arrangement of the brush in the vertical direction makes the cleaning of the coat at the torso and head easier.

The brush is accessible from all sides and rotates in every direction and nearly every angle, so each part of the animal's body can be reached.

Furthermore, there is no risk of jumping up as with horizontal brushes!

  • the HAPPYCOW Swing series is automatically activated by the animals slightly deflecting the brush
  • high-quality bristles ensure a long service life
  • optimised brushes ensure that animals are happy to use them
  • Continuous lubrication of the gear over the machine's entire lifetime
  • intelligent electronics for fault-free and low-maintenance operation
  • control with clearly visible display to indicate the operating status
  • variable setting options for brush running time (10 - 300 s)
  • the changing direction of the brush after ever activation ensures even wear of the brushes
  • the torque safety shutdown stops the brush when it encounters too much resistance, ensuring safety in the barn
  • plug ready for connection to 230 V socket
  • all steel parts are hot dip galvanised

a quality product developed and produced by Kerbl

Items
Ref. no.ColourWidthDepthHeightPUPallet
18860-ENred / blue49 cm134 cm190 cm112 PAL2 PAL
Accessories
Ref. no.DescriptionColoursuitable forPU
18881Spare Brush HAPPYCOW MaxiSwingred / blue18860, 188651


Effective cleaning from head to torso: Thanks to the vertically oscillating brush, the cow cleaning machine effortlessly reaches all parts of the body from head to rump and ensures thorough cleaning.

Suitable for all animal sizes: the scratching brushes from the HAPPYCOW Swing range are available in different sizes and are therefore suitable for different animal sizes from young animals to adult cattle.

Can be activated independently by the animal: the HAPPYCOW Swing series is automatically activated by the animals slightly deflecting the brush. This allows the cows to satisfy their scratching needs independently at any time.

Quality made in Germany: high-quality bristles guarantee many years of use, permanent lubrication of the gear and intelligent electronics ensure low-maintenance, fault-free operation.

Individually controllable and secure: the brush running time is variably adjustable (10 - 300 s), while a torque-dependent safety cut-out in the event of excessive resistance ensures safety in the barn.

a quality product developed and produced by Kerbl

Technical data
18860-EN
Voltage230 V
Mains frequency50 Hz - 60 Hz
Output550 W
Speed50 rpm
Weight105 kg
Protection classIP56
Bristle materialPolypropylene
Technical data18860-EN
Voltage230 V
Mains frequency50 Hz - 60 Hz
Output550 W
Speed50 rpm
Weight105 kg
Protection classIP56
Bristle materialPolypropylene
